RUFinal inspection before delivery ensures correct surface finish, appearance, and packaging quality.
ISO 9001 Certified Two Socket Cross
Better Prices
Various Surface Treatments Available
Comprehensive After Service
Get Goods Faster
Two Socket Cross Structural Pipe Fittings are designed to connect upright pipes with two perpendicular pipes in the same plane. Manufactured from high-quality cast iron, stainless steel, or aluminum, these fittings undergo strict inspection and advanced surface treatment. They are widely used in railings, construction frameworks, and DIY projects, providing a secure, durable, and flexible connection solution.
Our Two Socket Cross Structural Pipe Fittings are available in multiple sizes and materials to meet different construction needs. They can be made of malleable iron, ductile iron, or customized materials, and are offered with hot-dip galvanizing, powder coating, or other surface treatments for enhanced durability. With size options ranging from 26.9mm to 60.3mm, and customizable specifications, they can perfectly match your project requirements.
| Pipe Info | |||
 | |||
| Material | Carbon Steel | ||
| Surface | Hot Galvanized / Powder Coating | ||
| Color | Refer To Pantone Color Card | ||
| Pipe Sizes Comparison | |||
| Size | Inner Diameter | Outer Diameter | |
| Nominal (DN) | in | mm | |
| T | 15 | 1/2" | 21.3 |
| A | 20 | 3/4" | 26.9 |
| B | 25 | 1" | 33.7 |
| C | 32 | 5/4" | 42.4 |
| D | 40 | 3/2" | 48.3 |
| E | 50 | 2" | 60.3 |
| Color only refers to the color of the powder coating. The powder coating of the pipe will allow for color tolerance, Kindly contact us for details. The quality of the tube will meet the usage requirements in most scenarios. For special scenarios, Kindly contact us for performance testing. | |||
| Basic Info Table of Fittings | |||||||||||
 |  | ||||||||||
| Name | 119 Two Socket Cross | ||||||||||
| Material | Malleable Iron / Ductile Iron | ||||||||||
| Surface | Hot-dip Galvanized / Double Galvanized / Powder Coating / Raw Black | ||||||||||
| Color | Refer To Pantone Color Card | ||||||||||
| Pipe Sizes Comparison | Surface Finishing & Code | Dimensions(mm) | |||||||||
| Size | DN | in | mm | Hot-dip Galvanized | Double Galvanized | Powder Coating | Raw Black | a | b | C | D |
| T | 15 | 1/2" | 21.3 | HM-G-119-T | HM-D-119-T | HM-PC-119-T | HM-B-119-T | 70 | |||
| A | 20 | 3/4" | 26.9 | HM-G-119-A | HM-D-119-A | HM-PC-119-A | HM-B-119-A | 80 | |||
| B | 25 | 1" | 33.7 | HM-G-119-B | HM-D-119-B | HM-PC-119-B | HM-B-119-B | 96 | |||
| C | 32 | 5/4" | 42.4 | HM-G-119-C | HM-D-119-C | HM-PC-119-C | HM-B-119-C | 120 | |||
| D | 40 | 3/2" | 48.3 | HM-G-119-D | HM-D-119-D | HM-PC-119-D | HM-B-119-D | 135 | |||
| E | 50 | 2" | 60.3 | HM-G-119-E | HM-D-119-E | HM-PC-119-E | HM-B-119-E | 168 | |||
Two Socket Cross fittings are essential in structural systems that require multiple perpendicular pipe connections for added stability. They are engineered with a central socket and two opposing sockets, ensuring strong pipe fastening with hex bolts. HULK Metal produces these fittings with advanced materials and precision casting to guarantee durability and resistance against wear and corrosion. They are suitable for both industrial-scale applications and custom DIY structures.
The Two Socket Cross is designed to connect two pipes that are perpendicular to a single upright pipe. The two connected pipes remain aligned on the same straight line and lie within the same plane. This design enhances rail density and strengthens structural frameworks, making it highly suitable for guardrails, handrails, and multiple construction systems requiring durable, precise alignment.
In guardrail and handrail systems, the Two Socket Cross provides uprights with two connecting sockets to increase the density and stability of rails.
In DIY structures, it allows for the addition of two perpendicular sockets to a single upright pipe.
l It can only be used in ongoing construction systems. For finished systems, please choose Add-on Two Socket Cross.
l If you need two perpendicular sockets at a corner, use a 90 deg Side Outlet Tee (Corner Middle Cross) for correct installation.
The central socket fits over the upright pipe, while two opposing sockets hold the connecting pipes. Each socket and sleeve features a hex bolt to secure the pipes tightly, ensuring stability and ease of installation.
When installed, the upright pipe passes through the central sleeve, while the two opposing pipes are inserted into the sockets. Tightening the hex bolts locks all pipes securely in place, creating a strong and stable framework connection.
Two Socket Cross fittings can be made from cast iron, stainless steel, or aluminum, offering flexibility for different applications.
Available in malleable iron and ductile iron, cast iron Two Socket Cross fittings combine affordability with strength. They are suitable for most railing and framework applications, offering solid performance and high durability for both indoor and outdoor structural use.
Stainless steel Two Socket Cross fittings provide superior corrosion resistance, strength, and aesthetics. They are ideal for projects requiring long-lasting performance in harsh environments, including coastal areas or chemical industries, where exposure to moisture, salt, or chemicals demands maximum durability.
Aluminum Two Socket Cross fittings are lightweight yet durable, making them perfect for DIY projects and lightweight frameworks. They offer excellent resistance to rust and are easier to handle during installation, providing flexibility for customized or temporary structural systems.
Different surface treatments ensure better corrosion resistance and suitability across diverse environmental conditions, from heavy industry to outdoor installations.
Hot-dip galvanizing applies a thick zinc coating over the fitting, offering strong corrosion resistance. It is especially suitable for outdoor projects and humid environments where rust is a major concern. The process creates a durable, long-lasting protective layer, ensuring fittings maintain strength and stability under challenging weather and usage conditions.
Double-coating galvanizing combines hot-dip and electro-galvanizing for superior durability. The dual process ensures thicker and more uniform coating, maximizing protection against rust and extending service life. It is highly recommended for heavy-duty projects requiring both enhanced performance and aesthetic appearance in harsh or industrial environments.
Powder coating provides a customizable surface finish available in various colors. The coating offers strong protection against corrosion, scratches, and weather damage. It is suitable for both indoor and outdoor systems where appearance and performance are equally important, making it popular in architectural, commercial, and DIY structural applications.
l Confirm whether the Two Socket Cross size meets the system requirements.
l Ensure the surface treatment is suitable for the intended environment.
l Check whether it complies with local installation standards.
A reliable supplier must have strong production capacity and extensive industry experience. This ensures stable supply even for bulk orders. HULK Metal has advanced casting, machining, and surface treatment facilities, along with 16+ years of experience, making sure every Two Socket Cross order is delivered with consistent quality.
Choose suppliers with strict ISO-certified quality management systems and advanced testing equipment. This guarantees that every product meets international standards. HULK Metal performs dimensional, surface, and performance inspections throughout production, ensuring that the Two Socket Cross fittings you receive are reliable and defect-free.
A good supplier provides customization in size, material, and surface treatment while offering technical consultation. HULK Metal's engineering team can design solutions that perfectly fit your project needs, ensuring both functionality and cost-effectiveness. This technical support reduces risks and helps you complete projects more efficiently.
Ensure your supplier offers responsive after-sales support and reliable logistics. HULK Metal provides professional packaging, global freight consulting, and comprehensive after-service. Any quality issues are resolved with returns, replacements, or restocking. This ensures smooth cooperation, timely delivery, and a safer purchasing experience for large-scale projects.
A: A fully equipped quality inspection center, rigorous testing procedures, and a complete quality assurance system ensure each product meets international standards before shipment.
A: Pricing depends on raw material, size, surface treatment, and quantity. As a factory, we offer competitive prices and real-time quotations.
A: Our prices are based on high quality. Larger orders can secure better discounts. With the same quality level, HULK Metal guarantees more competitive offers.
A: MOQ depends on size and customization requirements. Contact us directly to get a specific quotation that fits your project's needs.
A: Standard delivery is around 30 days. Larger orders improve efficiency but never exceed 45 days. Custom timelines can be arranged.
A: Hot-dip galvanizing, double-coating galvanizing, and powder coating are available. Custom powder colors may require a MOQ.
A: We serve clients in over 50 countries across Europe, North America, South America, Africa, and Southeast Asia.
A: Cast iron, stainless steel, and aluminum. Full mold sets are available for cast iron; other materials may require OEM services.
A: Standard sizes range from 26.9mm to 60.3mm, and we can customize based on your project requirements. Custom molds can be developed.
A: We support T/T, L/C, and flexible delivery terms such as FOB, CIF, and EXW. Details can be customized based on agreements.
We carefully confirm your requirements, including surface treatment, order quantity, packaging, delivery time, and payment terms. This ensures every production detail aligns with your expectations and project schedule before manufacturing begins.
We source high-quality malleable iron, ductile iron, or stainless steel from certified suppliers. Each batch undergoes chemical and physical testing to ensure it meets strength, durability, and environmental standards before production starts.
Our advanced factory integrates automated casting, machining, and surface treatment lines. Each step is strictly monitored to maintain stable quality, improve efficiency, and reduce production errors, ensuring every Two Socket Cross meets ISO-certified standards.
The fittings are cast using advanced molding technology to ensure uniform structure and strength. This process guarantees precision dimensions, strong mechanical properties, and consistent quality for bulk orders.
After casting, burrs and impurities are removed, and surfaces are smoothed through finishing processes. This step ensures each Two Socket Cross is precise, easy to assemble, and ready for further treatment.
Dimensional, strength, and appearance inspections are conducted to detect defects. Only fittings that pass inspection move to the next stage, ensuring high-quality production and eliminating unqualified products early.
We apply galvanizing or powder coating based on requirements. Each treatment enhances corrosion resistance and appearance, ensuring the fittings are durable enough for outdoor and industrial applications.
A second inspection ensures the treated fittings meet thickness, adhesion, and appearance standards. This double-check guarantees consistent quality before packaging and delivery.
Products are packed securely in cartons or pallets to prevent damage. With professional logistics planning, goods are shipped efficiently worldwide, meeting your requested delivery terms.
Once you receive the goods, you may inspect quality and quantity. Any product defects are covered by our return, exchange, and restocking service, ensuring worry-free cooperation.
At HULK Metal, strict quality control ensures every Two Socket Cross Structural Pipe Fitting meets international standards. From raw material testing to finished product inspection, we monitor every stage. Dimensional checks, usage simulations, and pre-shipment inspections guarantee consistency and reliability. Our comprehensive system reduces defects and ensures buyers receive fittings with excellent performance, durability, and safety, giving you confidence in every bulk order.
Final inspection before delivery ensures correct surface finish, appearance, and packaging quality.
Every batch is counted and recorded to guarantee accurate delivery quantities.
We simulate installation and load-bearing tests to ensure fittings perform reliably under actual working conditions.
Precise measurement tools ensure fittings meet size specifications, preventing assembly errors and ensuring compatibility with tubes of different diameters.
HULK Metal operates modern factories with advanced casting, machining, and surface treatment facilities. Each department is strictly managed under ISO9001 standards, ensuring consistent quality and high productivity. Our integrated production and QC systems allow us to handle large bulk orders while maintaining precision and durability. With warehousing and logistics support, we provide clients with one-stop solutions from production to delivery.
HULK Metal offers Two Socket Cross Structural Pipe Fittings with higher certifications, stronger corrosion resistance, and customized production solutions. With advanced production facilities and a professional technical team, we guarantee quality, efficiency, and compliance with international standards. Clients benefit from competitive prices, comprehensive after-service, and long-term supply stability. Choosing HULK Metal means partnering with a supplier dedicated to quality, innovation, and customer satisfaction in every order.
