4 times Safety Factor Eye Slip Hooks
Cheaper and Higher Quality
QA Services
Get Goods Faster
HULK Metal's supply chain can complete the procurement of raw materials, production and delivery of orders faster. We provide a more complete range of eye slip hooks and better services to help you complete your procurement tasks faster.
HULK Metal can provide eye slip hooks in 7 sizes from 1/4" to 3/4" in both carbon steel and alloy steel, and in three surface treatments: electro-galvanized, hot-dip galvanized and powder sprayed. The table provides detailed product parameters, you can view them, or click the button on the upper right to download the catalog to learn more.
| NAME | US Type Slip Eye Hooks | ||||||||
| CODE | SIZE(IN) | W.LL/lbs(4:1) | DIMENSIONS(MM) | WEIGHT | |||||
| CARBON | ALLOY | φ | R | L | M | E | |||
| HM-USESH-14 | 1/4" | 1950 | 2750 | 12.7 | 65 | 92 | 68.5 | 23 | 0.4 |
| HM-USESH-516 | 5/16" | 2875 | 4300 | 16 | 72.5 | 106 | 76 | 26 | 0.62 |
| HM-USESH-38 | 3/8" | 4000 | 5250 | 18 | 86.5 | 124 | 89.5 | 33 | 1.11 |
| HM-USESH-716 | 7/16" | 5000 | 7000 | 20.5 | 98.5 | 142 | 108 | 40 | 1.56 |
| HM-USESH-12 | 1/2" | 6500 | 9000 | 23 | 109.5 | 156 | 116.5 | 43 | 2.1 |
| HM-USESH-58 | 5/8" | 9250 | 13500 | 28.8 | 132.5 | 195 | 143 | 52 | 3.9 |
| HM-USESH-34 | 3/4" | 12500 | 19250 | 35 | 147.5 | 222 | 169 | 55 | 6.93 |
When we are familiar with the product, we can find one among many suppliers that can provide better service and high-quality products. A good supplier will tell you more because he can do what he says.
It is produced from a section of high-performance steel bar by heating, bending, die forging, deburring, finishing and surface treatment. It is designed to link the chain, wire rope, cable, etc. of the pulling facility and the pulling point of the pulled object such as chain, wire rope, cable.
Its materials are mainly alloy steel and carbon steel. These two materials need to be made into the same size, so they will show two performances. This performance has been mentioned in the specification table, you can browse it in detail.
Tips: Unscrupulous merchants will make a big fuss about raw materials: for example, using waste materials (without a material list, it is difficult to identify the material properties) will reduce costs but it will be difficult to guarantee the quality of the order. When purchasing, please make sure you can see the material list and see what raw materials are used, obtain the production video or ask the process supplier to live broadcast the production process.
It is forged in one time, but can be divided into two parts according to function: hooks eye and hooks body, which are the pulling device end and the pulled end respectively.
It is a hole-shaped structure that is convenient for connecting links, wire ropes and cables to pass through. It is used to understand the tension facility end.
When using it, it is necessary to pay attention to the following: the diameter of the connecting links, wire ropes and cables needs to be smaller than the diameter of the hooks eye.
It is a hook-shaped structure with a larger inner cavity than the opening, which allows the chain to pass through and slide inside. We can use it to connect most objects within its load range.
It can be classified according to opening size, surface treatment, strength, material, etc.
Its common sizes are 1/4", 5/16", 3/8", 7/16", 1/2", 5/8", 3/4". Choosing the right one requires considering the thickness of the chain.
Common surfaces include electro-galvanizing, hot-dip galvanizing and powder coating. The main use environment needs to be considered.
There are 2 types: high-performance carbon steel and high-performance alloy steel. You need to compare the table to choose.
G30, G43, G70, G80, G100。
It can be used in two main scenarios: traction and lifting, and can also be combined with other tools for bundling.
Before using, you need to consider whether the load capacity of eye slip hooks can meet the requirements. Its opening size needs to be slightly larger than the thickness of the steel bar of the chain.
Depending on the material of the link, there are two situations.
Use connecting links to link the eyes of hooks and the closed loop at the end of the chain or wire rope.
Directly link the ends to the eyes of hooks.
Two situations can be considered when using:
When the width of the chain is smaller than the width of the inner cavity, the entire chain can be placed in the inner cavity;
When the width of the chain is larger than the width of the inner cavity, it can be hooked on only one side of the chain link.
It is forged from a single billet. It usually goes through the following steps:
1. Calculate the volume of each eye slip hooks and purchase steel rods of appropriate thickness;
2. Test the quality of raw materials and use them for order production if they pass the test;
3. The fully automatic sawing machine cuts the whole steel bar into specific lengths to make billets;
4. The electromagnetic induction tube heats the blank to a specific temperature;
5. Bend the blank into a specific arc;
6. The bent blank is placed into the hot section mold;
7. After the mold is closed, open it again to get the semi-finished product of eye slip hooks;
8. Use a punching die to cut off the flash;
9. After cooling, conduct strict sampling inspection to ensure that the products are qualified before finishing;
10. Finishing includes shot blasting, surface treatment, etc.
11. We will package the eye slip hooks according to your requirements. We can customize the packaging material and appearance.
12. Delivery and after-sales.
Note: The entire process can be automated, but it is only recommended when you need to purchase orders of hundreds of thousands of pieces, because adjusting the entire assembly line is very time-consuming. Small batch orders are more cost-effective when done manually.
We have a fully equipped quality inspection center. Tensile testing machine, thickness gauge, hardness tester, electron microscope, photometer, vernier caliper, salt spray tester and other equipment and instruments can complete the inspection of various data and give a detailed inspection report under the operation of professional inspectors.
We can use electron microscope to detect the internal structure of raw materials, photometer to detect the composition of materials. Some raw materials also need to be tested for mechanical properties.
We will use a tensile force of 4 times the safety factor to complete the load limit test. And provide test pictures, videos, etc.
At the request of the customer, we can strictly test the rust and corrosion resistance of Eye Slip Hooks.
Our forging factory has more than a dozen forging machines that can start the production of Eye Slip Hooks at the same time to shorten its production cycle. The fully equipped quality inspection center can ensure that each batch of goods meets your quality requirements. The closely cooperated surface treatment factory can complete high-standard galvanizing and powder coating faster. You can click to enter the details page to fully understand.
HULK Metal offers high-quality foot anchors designed for secure lifting of precast concrete elements. Our CE and ISO 9001 certified lifting pin anchors ensure a threefold safety factor, shorter production cycles, and prompt delivery.
HULK Metal has supplied tens of millions of Lifting Pin Anchors ranging from 1.3 tons to 32 tons to hundreds of buyers around the world. We have a full range of products and a complete supply chain to provide you with quality services. We provide quality assurance services. Please feel free to inquire.
Q345/CM490/20M2/45#/Others
Galvanized/Black
1.3~45.0
≥3
HULK Metal stands out as a leading manufacturer of lifting eye anchors, specializing in precast concrete lifting eye anchors that meet stringent CE certification with a 3 times safety factor.
Q345/CM490/20M2/45#/Others
Galvanized/Black
1.3~5.0
≥3
CE Certified Spherical Head Lifting Anchors
All Size of Spherical Head Lifting Anchors
Can Pass 3 Times Safety Equal
Lifting Pins for Precast Concrete supplied by HULK Metal are CE certified. We can supply Lifting Pins that can pass the tensile test of 3 times the safety factor and strictly implement the IS0 9001 standard to provide high-quality services.
Wavy tail anchor is made of high-performance steel pipe and rebar extrusion after bending. Its SWL range is between 0.5 and 8.0 tons. There are two thread standards, M and RD.
HULK Metal is a well-known supplier in China, providing high-quality and cost-effective Precast Lifting Thread Insert. With a complete supply chain and a professional team, we have provided flat end insert, solid rod insert, Tubular insert and others to global customers. We provide complete QA services. Looking Forward Your Inquiry.
HULK Metal is one of the high-quality Flat End Lifting Insert suppliers in China. In order to provide better services and products, we have integrated a complete supply chain. We strictly implement ISO 9001 management, and after years of development, we can now supply a full range of CE certified Flat End Lifting Insert.
Solid Rod Lifting Inserts supplied by HULK Metal have passed the CE certification. They can pass the tensile test with 3 times the safety factor. We strictly implement ISO 9001 standards to manage the entire supply chain to ensure that we can provide you with better Solid Rod Lifting Inserts and services.
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Fixing sockets with bent ends, also known as fixing inserts with bent ends, is essential for anchoring in precast concrete. These sockets provide robust points for fixing elements, featuring a bent design that enhances grip and stability.
Tubular Lifting Insert supplied by HULK Metal has passed CE certification. Tubular Lifting Insert can pass the 3 times safety factor tensile test, and each batch of goods has a comprehensive test report.
HULK Metal can provide you with RD and M standard 12-45 thread, SWL 0.5 to 8.0tons of Long Wavy Lifting Insert. Its international general standard is CE, which needs to pass the 3 times safety factor tensile force test.
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Flat End Lifting Socket
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Q345/20#/Stainless steel/Others
Galvanized/Black
8~52
≥3
Plate spread anchors from HULK Metal feature a welded steel plate and head design, embedded in concrete for edge lifting. Available in various sizes with galvanized options, they support loads up to 10 tons safely.
Unilateral erection anchors serve as specialized lifting inserts for precast concrete, designed for one-sided loading during element erection. They integrate with ring clutches and recess formers, providing stable anchor points that enhance safety and reduce panel stress in construction applications.
HULK Metal supplies flat foot anchors crafted from premium alloys for secure lifting in precast concrete projects worldwide.
HULK Metal stands as a reliable erection anchor supplier in China, delivering high-standard products for precast concrete lifting. Our anchors ensure secure handling with superior strength and corrosion resistance, backed by comprehensive production support for bulk orders.
HULK Metal supplies CE and ISO9001 certified spread anchors with reliable safety factors, faster delivery, and professional support. Choose our spread anchors for superior quality and complete precast lifting solutions.
HULK Metal delivers high-quality two-hole anchors, designed for secure lifting of precast concrete elements. Certified with CE and ISO 9001, our anchors ensure safety, durability, and efficiency.
High-quality dog bone lifting eye with CE and ISO9001 certification. Strong, safe, and durable for precast concrete lifting. Shorter production cycle and faster delivery from trusted Chinese supplier HULK Metal.
HULK Metal supplies CE and ISO 9001 certified lifting clutch for pin anchor with 5 times safety factors, shorter production cycles, and complete after-sales support for global precast concrete projects.
Dog Bone Lifting Eye With Chain supplied by HULK Metal can pass the 5 times safety factor test and has been CE certified. We can provide 1.3 to 20 tons load groups.
Ring Clutch supplied by HULK Metal is CE certified and can pass the tensile test with a safety factor of 5. We have integrated a complete supply chain and formed a complete team to provide better products and services.
Precast Concrete Lifting Eyes supplied by HULK Metal has passed CE and ISO 9001 Certified and can passed 5 times safety factor testing. HULK Metal is an experienced manufacturer in China. Looking forward your inquire.
Q345/35CrMo/Others
Galvanized/Black/Powder-coat
1.3~32.0
≥5
Precision Casting
HULK Metal has a well-established supply chain to provide you with a full range of Clevis Slip Hooks, such as G43, G70, G80, CE marked, with latch or none, electro-galvanized, hot-dip galvanized or powder coated. We strictly implement ISO 9001 quality management and have a professional team to provide better services. We are committed to being your office in China, helping you with all aspects of your orders in China.
We have provided customers in more than 100 countries and regions around the world with Clevis Grab Hooks with strength standards such as G43 70 80 that can pass 2 to 4 Times Safety Factor detection.
HULK Metal is an experienced eye grab hooks supplier in China. We have integrated a complete supply chain and formed a professional team to provide better products and services. We can provide eye grab hooks with various specifications and surface treatments.
HULK Metal is an experienced supplier in China, providing Eye Slip Hooks in various materials, strengths, certifications, surface treatments and sizes. We have established a complete supply chain to ensure that raw materials, production and delivery are under control to provide higher quality and low-cost lifting hooks.
Rubber/Plastic
1.3~45.0
HULK Metal can provide a variety of precast magnetic formers. With higher quality and more affordable price, it is your best choice.
1. ISO 9001Certification
2. QA Services
3. Save More Money
4. Various Precast magnetic Formers
Rubber/Plastic
0.7~26
As one of the excellent magnetic recess former suppliers in China, HULK Metal has advanced factories and perfect supply chain to provide you with high-quality products and services.
HULK Metal can provide CE-certified magnets for precast lifting and fixing inserts or sockets. Our factory has advanced machining equipment, laser cutting machines, and assembly lines, which can more efficiently complete CE-certified precast lifting fixing insert socket magnet with a higher pass rate.
Electrical box magnets for precast concrete are magnets used to fix the electrical box in a specific position during the production of precast concrete. It is made of rubber bodies and NdFeB and can be used in square, round, and other shapes. The rubber part can be inserted into the electrical box, and the magnet part can fit firmly with the framework to embed the electrical box into the precast concrete.
HULK Metal's factory has advanced sheet metal cutting, bending, welding processes and equipment, which can efficiently complete CE certified Shuttering Magnets for Framework. We have a complete supply chain to help you handle all matters related to your order in China, which can help you save more time and energy. We can achieve full access to control costs so that you can complete your order with less money.
HULK Metal has an advanced CNC machining center, laser cutting center, and assembly center. Our factory strictly implements ISO 9001. Therefore, we can complete orders with a higher qualified rate faster.
Name Halfen Anchor Channel Precast Concrete Accessories
Molds Full Range Moulds
Materials Q235B / Stainless Steel / Customized
Process Rolling / Riveted / Welding / Customized
Surface Treatment Powder Coating / Galvanized / Black
Test Content & Data 1. Chemical composition; 2. Mechanical properties; 3. Metallographic inspection; 4. Inspection of appearance, size, shape and position tolerance;
Length(mm) 100~6050
High(mm) 15.25~48.5
Width(mm) 28~72
Name Halfen Channel Precast Concrete Accessories
Molds Full Range Moulds
Materials Q235B / Stainless Steel / Customized
Process Rolling / Riveted / Welding / Customized
Surface Treatment Powder Coating / Galvanized / Black
Test Content & Data 1. Chemical composition; 2. Mechanical properties; 3. Metallographic inspection; 4. Inspection of appearance, size, shape and position tolerance;
Length(mm) 100~6050
High(mm) 15.25~48.5
Width(mm) 28~72
Name Wire Loop Box Precast Concrete Accessories
Molds Full Range Moulds
Materials Wire Rope / Steel Plate / Customized
SL(mm)±10 60 / 80 / 100 / 120 /140
Name Cast in Channel Precast Concrete Accessories
Molds Full Range Moulds
Materials Q235B / Stainless Steel / Customized
Length(mm) 100~6050
High(mm) 15.25~48.5
Width(mm) 28~72
Q345/20#/Stainless steel/Others
Galvanized
0.8~25.0
6~32
≥3
Q345/20#/Stainless steel/Others
Galvanized
8~52
≥3
As a top metalworking service provider, we want to let every customer experience a sense of security in purchasing, sales, etc., and better realize their value through continuously defining new standards for products and services.
