Features:
1. Hot Galvanized or Double Coating
2. T to E Type Pipe Fittings
3. Deliver Goods Faster
4. Bigger Order Cheaper Price
5. QA Service
6. Comprehensive After Service
1. Hot Galvanized or Double Coating
2. T to E Type Pipe Fittings
3. Deliver Goods Faster
4. Bigger Order Cheaper Price
5. QA Service
6. Comprehensive After Service
No. 101 galvanized pipe handrail fittings are used to connect two pipes into a "T" shape. It is also called Short Tee. One pipe is inserted into the socket and the other one passes through the channel above. It can add a vertical guide to a pipe. It can be used to add a horizontal guide to the uprights of a horizontal pipe handrail, and it can also increase the density of pipes for racks. In addition, it has many more uses to be developed.
It is very simple to assemble, just tighten the threads on it to achieve a tight connection with the pipe.
HULK Metal currently provides three galvanizing methods: electroplating heat and double coating. You can purchase according to your needs.
HULK Metal is a famous galvanized pipe handrail fittings manufacturer in China. We have our own foundry and a full range of molds to provide OEM and production services. We provide quality assurance services. You can rest assured to give us your orders.
Basic Info Table of Fittings | |||||||||||
MATERIAL | Malleable Iron / Ductile Iron | ||||||||||
SURFACE TREATMENT | Hot-dip Galvanized / Double Galvanized / Powder Coating / Raw Black | ||||||||||
COLOR | Refer To Pantone Color Card | ||||||||||
PIPE SIZE | |||||||||||
MATERIAL | Carbon Steel | ||||||||||
SURFACE TREATMENT | Hot Galvanized / Powder Coating | ||||||||||
COLOR | Refer To Pantone Color Card | ||||||||||
Pipe Sizes Comparison | |||||||||||
PIPE CODE | Inner Diameter | Outer Diameter | |||||||||
Nominal (DN) | in | mm | |||||||||
T | 15 | 1/2" | 21.3 | ||||||||
A | 20 | 3/4" | 26.9 | ||||||||
B | 25 | 1" | 33.7 | ||||||||
C | 32 | 1 1/4" | 42.4 | ||||||||
D | 40 | 1 1/2" | 48.3 | ||||||||
E | 50 | 2" | 60.3 | ||||||||
Color only refers to the color of the powder coating. The powder coating of the pipe will allow for color tolerance, Kindly contact us for details. The quality of the tube will meet the usage requirements in most scenarios. For special scenarios, Kindly contact us for performance testing. | |||||||||||
101 | Pipe Size | Surface Finishing | Dimensions(mm) | ||||||||
Hot-dip Galvanized | Double Galvanized | Powder Coating | Raw Black | a | b | c | d | ||||
CODE | T | HM-G-101-T | HM-D-101-T | HM-PC-101-T | HM-B-101-T | 35 | |||||
A | HM-G-101-A | HM-D-101-A | HM-PC-101-A | HM-B-101-A | 41 | ||||||
B | HM-G-101-B | HM-D-101-B | HM-PC-101-B | HM-B-101-B | 46 | ||||||
C | HM-G-101-C | HM-D-101-C | HM-PC-101-C | HM-B-101-C | 60 | ||||||
D | HM-G-101-D | HM-D-101-D | HM-PC-101-D | HM-B-101-D | 68 | ||||||
E | HM-G-101-E | HM-D-101-E | HM-PC-101-E | HM-B-101-E | 84 |
HULK Metal has passed ISO 9001 quality management certification and can provide higher quality production services. Our quality control center has advanced salt spray testers, impact testers, photometers, hardness testers, electron microscopes, and other instruments to test the various indicators of galvanized pipe handrail fittings according to your requirements. We will also attach a complete test report to each batch of goods and provide quality assurance services.
We have a close cooperation with the galvanizing factory, which can provide better quality electro-galvanized, hot-dip galvanized and double-coated galvanized pipe handrail fittings. Double-coated is first hot-dip galvanized and then electro-galvanized, with better appearance, better anti-oxidation and corrosion resistance than hot-dip galvanized, and more expensive. Electro-galvanizing has the lowest price. The single coating is very thin, and the cost of thickening electroplating will be very high. Hot-dip and double-coating are the best choices.
The premise of low price is the same quality. We have achieved the ability to provide galvanized pipe handrail fittings of the same quality at a lower price through unified and strict supply chain management. Material cost, production cost, packaging cost, and transportation cost can all be controlled most effectively. We can save more in larger orders. We will share this part of the profit with you. We look forward to your inquiry.
We have advanced fully automatic molding machines, fully automatic pouring machines, shot blasting machines, and cutting machines, which can quickly complete mold manufacturing, pouring, cutting, shot blasting and other production. We will develop more complete solutions to complete orders faster based on your purchase quantity and delivery requirements. We have a logistics center to solve the transportation problems of goods in China. The International Freight Consulting Center can help you find a more suitable freight company.
High-quality services can help you save more time and energy. We have formed a complete team to serve as your office in China to handle all matters related to your orders in China. You can learn about the production progress of your orders in real time through us, and participate in the production through the video calls we provide. You can get first-hand information about your orders without coming to China. You can complete your procurement tasks faster through us.
HULK Metal
The Most Trusted Galvanized Pipe Handrail Fittings Suppliers In China.
Galvanized Pipe Handrail Fittings is made of cast iron and is produced by sand casting. The specific process is: making molds, metal smelting, pouring, cooling, sanding, cutting, grinding, shot blasting, and surface treatment. The finished product can be packaged and delivered to customers. There are usually two ways for foundries to produce it: manual production (for small batch orders) and mechanical production (for large batch orders).
HULK Metal has an advanced foundry and a full set of molds to produce 101 Short Tee with T, A, B, C D, E pipe types. We have a complete supply chain to provide better services and have more than 20 years of global service experience. You can contact us at any time to visit the factory and place your order with us after understanding our production capabilities.
In-depth understanding of your requirement.
Custom production solutions.
Schedule the production schedule.
Start producing you order.
Monitor production process.
Inspect the product quality irregularly.
Customized packaging solutions.
Pre-shipment inspection and arrangement of shipment.
After Service.
You can see them when our workers are working.
We will Show them to you with photo, vidio, or live chat any methods you want.
HULK Metal's service was excellent. I will place more orders with them.
